Excavator weight: 28 ÷ 55 tons

Attachment operating weight*: 3450 Kg

Max opening: 1190 mm

Height: 2590 mm

Width: 1630 mm

Jaw width: 560 mm

Oil delivery: 180 ÷ 260 l/min

Maximum working pressure: 350 bars

Maximum clamping force at tip: 120 tons

Maximum clamping force at shears: 380 tons

Shear length: 240 mm

Max cutting diameter: 50 mm

Min. closure time: 2,5 s

Min. opening time: 2,5 s

Hydraulic connections: 1”

Mounting bracket compatibility: HP 7000 - HP 9000
